Part Case Study
From pen-and-paper sketch to precision-cut part — in seconds.
↓ BeginStep 01
On the workshop floor, measurements were taken and the part was sketched by hand — nothing more than pen and paper.
Step 02
A photo of the sketch was run through Drawing 2 DXF. Within seconds, a production-ready DXF file was generated — along with full quoting metrics.
Step 03
The part was cut from the specified stainless steel grade and thickness. Installed on site — fits perfectly.
The Result
Drawing 2 DXF removes the bottleneck between idea and production.
